ITEM NO

PART NO

DESCRIPTION

RESTRICTED SPARES

501

B2562-65-SBGD

TAPE WIPER ASSY WITH PLATE

WPR-GSKT-RSTR

TAPE WIPER GASKET

504

HSG-D2562-33

HOUSING, WIPER

505

A2562-46R-SBGD

TAPE GUIDE SEAL ASSY

507

NPLB2562-32-2&3

NAMEPLATE, WIPER ON-OFF

511A

A2562-78F-SBGD

TAPE GUIDE SEAL – OPEN

519

SQR117S-B

SQUARE RING, 117S, BUNA-N

534

B2562-43

CRANK ASSY

542

SCLA2283-13-BZ

COLLAR, SECURING BRONZE

0208

GSK#TS-327

SEAL RING, TS VALVE, BUNA-N

556

B2562-20-SBGD

DRUM SHAFT ASSY

566

SNSA2360-4-4S

SENSOR HEAD, TRI W/BARREL (PES)

566S

SNSA2360-4-4SSS

SENSOR HEAD, TRI W/BARREL (PEEK)

568MC

THAB2317-50/15M

TAPE & HEADER ASSY, 50FT/15M

570MC

THAB2317-100/30M

TAPE & HEADER ASSY, 100FT/30M

568M

THAB2317-37M

TAPE & HEADER ASSY, 37/40M

569M

THAB2317-50-70M

TAPE & HEADER ASSY, 50/70M

599

HRN#EFBRC24C01

HORN, U/I & TRI

600

CVPB2455-13LEX

COVERPLATE, TRI

601

PBGA2272-17-AL

PUSH BUTTON GUARD

603

PCB2401-16-TPL

PCB, TRIMODE HUB

606

NPLB2401-11A

NAMEPLATE, TRIMODE – BASSEFA

609

PBCAMPN5040R

PUSH BUTTON SEAL CAP

613

B2562-77-ASSY

SENSOR STOWED INDICATOR

620

SPRA2562-76-4S

LEAF SPRING TAPE SEAL

623

NPLA2562-74-B

NAMEPLATE, SENSOR STOWED

624

NPLA2562-74-A

NAMEPLATE, SENSOR STOWED CAUT

625

STOB2562-79-B

PROBE STOP

626

SWT-TRI-ON-OFF

PUSH BUTTON SWITCH, TRI/OXY/TEMP

645

BRL-B2562-75

BARREL, SENSOR – U/I & TRIMODE

645S

SNS-MPC805

SENSOR HEAD, TRI NO BARREL (PES)

645A

SNS-MPC805A

SENSOR HEAD, TRI NO BARREL (PEEK)

650

BCCB2401-15-TRI

9V BATTERY CAP – TRIMODE

686

SNSA2615-17

OXYGEN SENSOR, NO BARREL

687

B2615-9-BRL-ASSY

BARREL, SENSOR – OXYGEN WITH CAP

694

PCB-D-2615-2

PCB, OXYGEN HUB

696

NPLAB2562-6-BAS

NAMEPLATE, OXYGEN HUB BASEEFA

697

BCB2615-7-02

BATERY CAP ASSY – OXYGEN

1001S

TAP40M-W-HOOK

40M SS SAMPLING TAPE W/SNAPHOOK

1002S

REL2562-352

TAPE REEL ASSY 7″ (TANK DRYNESS)

1002

REL2401-10-50/15

TAPE REEL ASSY – 15m

1003

REL2401-10-100/30

TAPE REEL ASSY – 30m

1004

REL2401-10-40M

TAPE REEL ASSY – 40m

1007

B2401-72-BS-SBGD

HUB ASSY, TRIMODE – BASSEFA

1011

BUT2562-39

BUTTON, REEL REST (NYLON)

1013

RNGB2401-4A

RING, HUB COVER

1014

B2562-35-R-SBDG

STORAGE TUBE ASSY – RESTRICTED

1014TSC

B2562-151-TS-C2

STORAGE TUBE ASSY – TS – C2.SS

1015

B2562-36-F-SBDG

STORAGE TUBE ASSY – OPEN

A2562-301-ANK52

STORAGE TUBE ASSY – ANK 52

1016

B2562-315-SBDG

HANDLE ASSY

1017

NPLA2378-1A

NAMEPLATE, REWIND (NO ADHESIVE)

1019

FRM2562-34R-ASSY

FRAME, 50, 100 / 15, 30M RESTRICTED

1021

FRM2562-38C-ASSY

FRAME, 40M RESTRICTED

1025

GL-A2401-65

GROUNDING LUG

1028

NPL2272-9G

NAMEPLATE, GROUNDING INST.

1029

NPLA2401-41

NAMEPLATE, OP INST, FM & BS

1030

SCRA2562-27

SCREW, THUMB – BRASS

1034

B2562-50R-SBDG

WIPER TO BARREL HOUSING ASSY – R

1035

BAT9V-522-TRANS

BATTERY 9 VOLT #522

1037

NPLA2562-40

NAMPLATE, REEL LOCK

1042

BRG2562-70-BR

BEARING, DRUM SHAFT – BRASS

1043

WSR10-.75X.5

WASHER, FLAT #10 9.75 OD X .049″ THK

1045

WSRU-SU-12-4S

WASHER, CURVED SPRING

1046

BND2562-28

SPRING BAND

1047

WSRA2562-28

WASHER, RETAINING – BRASS

1048

NPLA2562-32

NAMEPLATE, ZERO ULLAGE

1058

B2562-52-R-B-SBDG

STORAGE TUBE ASSY – RESTRICTED – SAM

1059

B2562-52-F-SBGD

STORAGE TUBE ASSY – OPEN – SAMP

1060TS

S2562TS-CPL-SHT

ADAPTOR TS CPLG (SAMPLING ONLY)

1060TT

A2562-372-TT-CPL-SHT

ADAPTOR TT CPLG (SAMPLING ONLY)

1062

CASE-TAPES-R

CASE, MOULDED CARRYING

1064

BAG-CARRY-“F”

BAG, CARRY – CANVAS

1070

GROUNDINGKIT

GROUNDING CABLE

1080

D2615-8-SBGD

OXYGEN SENSOR W/BARREL

1085

NPLA2615-21

NAMEPLATE, “WARN” OXYGEN SENSOR

1086

NPLA2615-24

NAMEPLATE, “IMP/ATT” OXYGEN SENSOR

1087

NPLA2615-10

NAMEPLATE, OP INST, OXYGEN

1088

BOB-A2670-1/2

SOUNDING BOB

A-2670-2-SS

SOUNDING BOB – STN STL

1090

SAMPLER D-2518-1

1/2 LTR SAMPLER 1-5/8″ X 18

1090B

SAMPLER D-2518-BOT.

1/2 LTR SAMPLER 1-5/8″ X 18 – BOTTOM

1090C

BTMS

BOTTOM SAMPLER

G001

THAB2317-15MC

15M GT TAPE & HEADER PET SERVICE

G002

THAB2317-20MC

20M GT TAPE & HEADER PET SERVICE

G003

THAB2317-30MC

30M GT TAPE & HEADER PET SERVICE

G004

THAB2317-35MC

35M GT TAPE & HEADER PET SERVICE

G005

THAB2317-15MCH

15M GT TAPE & HEADER CHEM SERVICE

G006

THAB2317-20MCH

20M GT TAPE & HEADER CHEM SERVICE

G007

THAB2317-30MCH

30M GT TAPE & HEADER CHEM SERVICE

G007A

THAB2317-35MCH

35M GT TAPE & HEADER CHEM SERVICE

G008

SGLA2562-146SG

PRIMARY SIGHT GLASS

G009

SGLA2562-147SG

SECONDARY SIGHT GLASS

G010

B2562-269-SBGD

GAS TIGHT WIPER

G011

B-2562-329-SG-WPR

PRIMARY SIGHT GLASS WIPER ASSY

G012

GSK2562-91BN-SML

BACKPLATE GASKET (SMALL) BUNA-N

G012A

GSK2562-91V-SML

BACKPLATE GASKET (SMALL) VITON

G013

GSK2562-91BN

BACKPLATE GASKET (LARGE) BUNA-N

G013A

GSK2562-91V

BACKPLATE GASKET (LARGE) VITON

G014

O/R-353

FRICTION STOP O-RING

G015

CPAA2562-141SG

CURSOR PIN, PRIMARY SIGHT GLASS

G016

RLRA2562-126SG

ROLLER GUIDE, TAPE SEAL

G017

B-2562-106-HUB-BRK

REWIND HANDLE (BRAKE ASSY)

G018

TAP40M-W-HOOK-CH

40M GT SAMPLE TAPE & HOOK CHEM.

G020

SCLA2283-5C-6S

STORAGE TUBE SECURING COLLAR

G021

VLVB2562-134G

VENT VALVE ACTUATOR & VALVE

G022

B2562-137-CH

CONECTOR HUB TO TAPE ASSY CHEM

G023

B2562-137-PETL

CONECTOR HUB TO TAPE ASSY PET

G024

HSEA2562-238SG

VAPOUR RETURN HOSE, SAMPLER

G025

BTLFL-A2562-185

BOTTLE FILL ATTACHMENT, SAMPLER

G026

CVR2562-323

BACKPLATE COVER (SMALL BOX)

G027

CVR2562-114

BACKPLATE COVER (LARGE BOX)

G028

B2562-100-R

GT GAUGING UNIT STORAGE TUBE

G029

A2562-302-ANK52

GT GAUGING UNIT STORAGE TUBE – ANK52

G030

B2562-267-TSC2

TS ADAPTOR B TO C2 SS

G030A

A2562-386-TT

TT ADAPTOR B TO TT

G030B

A2562-358-ANK52

MMC ADAPTOR B TO ANK 52

G031A

B2562-264-LWR-BRL

GT SAMPLER BARREL

G031B

B2562-264-LWR-VCV

GT SAMPLE VALVE (A-2318-55V)

G034

B-2562-314-SBGD-SML

SMALL GAS TIGHT BOX HANDLE

G035

B-2562-315-SBGD

LARGE GAS TIGHT BOX HANDLE

G036

B-2562-107-ARM

ANTI REWIND ARM

G037

BX-B2562-316-SBGD-SML

SMALL YELLOW BOX.

G038

BX-B2562-87-117-LG

LARGE YELLOW BOX

G039

RS-023V

SENSOR BARREL O-RING – PET.

G040

RS023T

SENSOR BARREL O-RING – CHEM.

G041

GAS 50-57-3N

STORAGE TUBE O-RING

G042

OR/2-301

WIPER HOUSING O-RING.

G043

GTBPSCR

BACKPLATE SCREW

G044

OR/2-007V

BACKPLATE SCREW O-RING

G045

GTSTSCR

GT STORAGE BARREL SCREW

G046

D-2562-121-ASSY

GT REEL ASSEMBLY

G047

D-2562-86

GT WIPER HOUSING

G048

B-2562-230-STB-BRL

STUB BARREL SAMPLER
